» DVM Test Report: Steady-State|Steady-State|Vin Maximum|100% Load

Test Details
Schematic 6.6.2_LTC3406B - DVM ADVANCED.sxsch
Test Steady-State|Steady-State|Vin Maximum|100% Load
Date / Time 12/10/2015 5:53 PM
Report Directory use_arbitrary_curve\Steady-State\Steady-State\VinMaximum\100% Load
Log File report.txt
Screenshot schematic.png
Status PASS
Simulator simplis
Deck input.deck
Init input.deck.init
Measured Scalar Values
Efficiency 66.3459%
ILOAD
AVG
1.50063
MIN
1.49625
MAX
1.50451
RMS
1.50063
PK2PK
8.25515m
ISRC
AVG
619.346m
MIN
466.026u
MAX
1.81961
RMS
973.383m
PK2PK
1.81914
Power(LOAD) 2.25938
Power(SRC) 3.40545
VLOAD
AVG
1.50562
MIN
1.50123
MAX
1.50951
RMS
1.50562
PK2PK
8.28261m
VSRC
AVG
5.49938
MIN
5.49818
MAX
5.5
RMS
5.49938
PK2PK
1.81914m
Measured Spec Values
Max_VLOAD PASS: Max. Output1 Voltage (1.50951) is less than or equal to Max. Output1 Voltage Spec (1.58025)
Min_VLOAD PASS: Min. Output1 Voltage (1.50123) is greater than or equal to Min. Output1 Voltage Spec (1.42975)
LOAD
VLOAD
ILOAD
SXGPH File simplis_pop1_19.sxgph
SRC
VSRC
ISRC
SXGPH File simplis_pop1_9.sxgph
default
CLK
ILOUT
SW
VOUT
VOUT-AC
SXGPH File simplis_pop1_14.sxgph
Other SXGPH Files
clock#pop simplis_pop1_1.sxgph
