» SIMPLIS DVM Test Report Overview

General
Schematic 6.3_LTC3406B - DVM ADVANCED.sxsch
Testplan dvm_advanced.testplan
Original Testplan Filename 6.5.2_promotescalar_final.testplan
Date / Time 2015-12-10 5:50 PM
Report Directory promote_scalars
Log File dvm_advanced.log
# of Tests Run 6 of 6 (6 of 6 Run, 2 Passed, 4 Failed, 0 Ran with Warnings, 0 Skipped)
Total Time 1m 2s
Design Specifications
Circuit Name LTC3406B
Description Synchronous Buck
Input 1 5.000 V (4.5 V to 5.5 V)
Output 1 1.505 V (±5%) @ 1.5 A
Switching Frequency 955kHz
Calculated Results
Gain Margin @ 1.505V (dB) 30.3822
Gain Margin @ 600mV (dB) 33.8124
Phase Margin @ 1.505V (deg) 36.9686
phase_margin 39.8687
Excel-compatible Results
Scalar Results dvm_advanced_table_scalars.txt
Spec Results dvm_advanced_table_specs.txt
Statistic Results dvm_advanced_table_statistics.txt
Statistic Specs dvm_advanced_table_statspecs.txt
Overview Graphs
Bode Plot Nominal Vout
GAIN
PHASE
SXGPH File simplis_ac2_78.sxgph
Source Test VOUT=1.505V|BodePlot|Vin Nominal|50% Load
Bode Plot
GAIN
PHASE
SXGPH File simplis_ac4_197.sxgph
Source Test VOUT=0.6V|BodePlot|Vin Maximum|50% Load
LOAD
VLOAD
ILOAD
SXGPH File simplis_pop2_61.sxgph
Source Test VOUT=1.505V|BodePlot|Vin Nominal|50% Load
LOAD
VLOAD
ILOAD
SXGPH File simplis_pop5_180.sxgph
Source Test VOUT=0.6V|BodePlot|Vin Maximum|50% Load
Test 1 of 6top ▲
Test Label VOUT=1.505V|Bode Plot|Vin Nominal|Light Load
Simulator simplis
Test Report VOUT=1.505V\BodePlot\Vin Nominal\Light Load\report.txt.html
Status FAIL
Test Time 10s
Test 2 of 6top ▲
Test Label VOUT=1.505V|Bode Plot|Vin Nominal|50% Load
Simulator simplis
Test Report VOUT=1.505V\BodePlot\Vin Nominal\50% Load\report.txt.html
Status PASS
Test Time 10s
Test 3 of 6top ▲
Test Label VOUT=1.505V|Bode Plot|Vin Nominal|100% Load
Simulator simplis
Test Report VOUT=1.505V\BodePlot\Vin Nominal\100% Load\report.txt.html
Status PASS
Test Time 10s
Test 4 of 6top ▲
Test Label VOUT=0.6V|Bode Plot|Vin Maximum|Light Load
Simulator simplis
Test Report VOUT=0.6V\BodePlot\Vin Maximum\Light Load\report.txt.html
Status FAIL
Test Time 7s
Test 5 of 6top ▲
Test Label VOUT=0.6V|Bode Plot|Vin Maximum|50% Load
Simulator simplis
Test Report VOUT=0.6V\BodePlot\Vin Maximum\50% Load\report.txt.html
Status FAIL
Test Time 10s
Test 6 of 6top ▲
Test Label VOUT=0.6V|Bode Plot|Vin Maximum|100% Load
Simulator simplis
Test Report VOUT=0.6V\BodePlot\Vin Maximum\100% Load\report.txt.html
Status FAIL
Test Time 10s
